Yamaha unveils the all-new Sight

Yamaha-Motor Philippines (YMPH) recently launched their latest offering in the entry-level commuter underbone segment during the 2017 YMPH dealer convention at Conrad Hotel in Pasay City. The all-new Sight is powered by a 114 cc air-cooled, single-cylinder engine which produces 6.4 kw @ 7000 rpm and 9.5 nm @ 5500 rpm. Equipped with fuel-injection system, Yamaha claims that the Sight can run up to 103.6 kilometers on a liter of fuel. The Sight also boasts of a 9-liter underseat storage and front disk brakes on both spoke wheel and cast wheel variants. Like most underbones, the Sight has a 4-speed auto-clutch transmission, making it easy to ride for novice and expert alike. This Euro 3 compliant commuter is offered in two price points: P 59,900 (spoke), P 62,900 (cast) and it will be available in nationwide dealerships beginning September 2017.

More Yamaha Sight 115cc photos here



Yamaha Sight Technical Specifications

ENGINE:

Engine type – Air-cooled 4-stroke, SOHC, 2-valve

Cylinder layout – Single cylinder Bore x Stroke – 50.0 × 57.9 mm

Compression Ratio – 9.3:1

Displacement – 114 cc

Maximum Power – 6.4 kW @ 7,000 r/min

Maximum Torque – 9.5 N•m @ 5,500 r/min

Starter System – Electric and Kick Starter Lubrication system – Wet sump

Engine Oil Capacity – 1.0 L

Fuel System – Fuel injection

Clutch Type – Wet, Centrifugal, Shoe and Multiple-Disc

Transmission Type – Constant mesh, 4-speed

Gear Ratios – 1st= 2.833 (34/12) 2nd= 1.875 (30/16) 3rd= 1.353 (23/17) 4th= 1.045 (23/22)

DIMENSION

Length X Width X Height – 1,940 mm × 715 mm × 1,075 mm

Wheelbase – 1,235 mm

Minimum Ground Clearance – 155 mm

Seat Height – 775 mm Curb Weight (with oil & full fuel tank) – 96 kg

Fuel Tank Capacity – 4.0 L

FRAMEWORK

Frame Type – Backbone

Front Suspension – Telescopic

Rear Suspension – Swingarm

Front Tire – 70/90-17 M/C 38P (Tube type)

Rear Tire – 80/90-17 M/C 44P (Tube type)

Front Brake – Disc Brake (Hydraulic Single Disc)

Rear Brake – Drum Brake (Mechanical Leading Trailing)

Headlight – 12V, 32/32Wx1

Meter Panel – Analogue with Gear Indicator

ELECTRICAL

Ignition System – TCI (Transistor Control Ignition

Battery Type – 12V / 3 Ah / NTZ4V
